This Battery Charger with Auto Voltage detection and Charging at 6, 12 and 24v are designed to effective charge all Automotive, Marine, Motorhome and Industrial type batteries.
Manufactured to the latest design parameters, they incorporate a micro-processor controlled 7 stage pulse charging system. It asseses the battery condition and size via it's unique Algorhythm.
It makes Charging Safer, easier and more effective. This all adds up to a prolonged battery life.
Charge batteries individually, or if the batteries are identical to each other you can charge them in banks.
Lithium Charging via mode button (12v only)
*Zero Volt Minimum start and old battery Sulphation repair (Rejuventation)
*Auto-detect selects 6V, 12V or 24V charging depending on battery connection
*Optimally Designed for All lead based Batteries, SLA, VRLA, AGM, GEL, AGM, CALCIUM, STARTING, CYCLING and LITHIUM Batteries (Lithium in 12V only).
*Short Circuit, Reverse Polarity, Overcharge, Over Temperature and Overload Protection.
*Bright Clear Digital LED LCD display, shows the charging stage status, volts and amps output and battery capacity.
*Complete, comprehensive 7 stage Charging
*This charger also offers a Continuous 13.5VDC power Supply. This also has short circuit and Overload protection.
*Faulty Battery indicators for if the battery being charged is completely dead and cannot be charged. Depending on what battery is being charged; 6V or 12V or 24V LED will flash if battery is faulty.
Type: 8 stage Battery Charger
Input Voltage: 175-255V /50-60Hz (GREAT FOR GENERATORS -Inverter Generators recommended)
Output Current: 30A
Output Voltage: 6V/12V/24V and 13.5VDC
Battery type: GEL, LEAD ACID, AGM, CALCIUM and 12v Lithium
Chargeable Battery Size: 17A/H to 600A/H
Working temperature: -15 to +55 Degrees Celcius
Start Voltage: 0V (as long as battery hasn't reversed polarity, or if battery hasn't been left totally flat for too long)
Unit size - 250mm x 200mm x 80mm high
Mounting Flanges attached as per Image.
