It offers features such as battery diagnosis that shows if a battery can receive and retain a charge, a special reconditioning function that restores stratified and deeply discharged batteries, unique maintenance charging and a temperature sensor for optimised charging regardless of the weather conditions. It also has a power supply mode which allows the battery to be disconnected from the vehicle without losing important configurations. The unique display allows the user to follow the entire charging process.
The MXS 10 is a fully automatic 8-step charger that delivers 10A to 12V batteries from 20–200Ah and is suitable for maintenance charging up to 300Ah. The charger is IP 65 classified (splash and dust proof), designed to protect vehicle electronics and non-sparking, reverse polarity protected and short-circuit proof. It is delivered with a 2-year warranty.
Auto: Fully automatic for optimal charging
12V: For all lead-acid batteries
Step 7: Fully charged battery
Step 8: Maintenance charging
COLD/AGM: Charging in cold conditions and AGM batteries
RECOND: Recondition of deeply discharged batteries
SUPPLY: Use the charger as a power supply
Rated Voltage AC 220–240VAC, 50–60Hz
Charging voltage NORMAL: 14.4V, COLD/AGM: 14.7V, RECOND: 15.8V, SUPPLY: 13.6V
Min battery voltage 2.0V
Charging current 10A max
Current, mains 1.0A rms (at full charging current)
Back current drain <1Ah/month
Ambient temperature -20°C to +50°C, output power is reduced automatically at high temperatures
Charger type 8 step, fully automatic charging cycle
Battery types All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity 20–200Ah, up to 300Ah for maintenance
Dimensions 197 x 93 x 49mm (L x W x H)
Insulation class IP65
