IP53 Equivalent multimedia Stereo head unit system.
Want that 'Old Skool' look to suit your Old Skool Vehicle? Or simply the ability to play you Old Skool Music Via the Old Skool Music Media, CD's, VCD's, MP3's, MP4's AND a built in AM/FM Radio.
All of which comes with an Old Skool remote to wrap up the complete Old Skool experience.
Quality system at an unbeatable price.
Information
Flip down Panel
Built in Amplifier
Voltage 12VDC (14.4vdc max)
4 x 50W Max Output
CD/MP3/WMA format
AM/FM Receiver
30 Station Auto Memory Store
PLL Lock Station
Auto Scan
Electronic Volume Control
Wireless remote control
Full wiring looms
Comprehensive User Manual (includes install instructions, instalation plate and bracket)
Specifications
Specifications:
power: 12-14.4vdc
load impedence: 4 ohms
4 x 50W Max Output
dimensions: 210x195x88mm (d x w x h)
mounting dimensions: 175x180x52mm (d x w x h)
DVD deck system
discs played: dvd, vcd 1.0/1.1/2.0/3.0 mp3, cd, cd-r, cd-rw, picture-cd
video system: AUTO/PAL/NTSC
Mounting angle: 0 to =/-30 degrees
VIDEO section
video system: 4:3 letter box and 4:3 pan scan
video output level: 1.0Vp-p 75 ohms
horizontal resolution: 500
AM tuner section
frequency range: 522-1620 (europe/china), 5130-710 (USA)
IF range: 450kHz
usable sensitivity(-20dB): 25dB
FM tuner section
tuning range: 87.5-108 (europe/china), 87.5-107.9 (USA)
IF range: 10.7MHz
usable sensitivity(-30dB): 15dB
signal-to-noise ratio: 60dB
stereo separation: 30dB(1KHz)
frequency response: 30-15000Hz
Due to continuous product adaptation, specifications may vary, and are subject to change.
