Voltage 12
CCA 140
MCA 201
PHCA 385
Capacity 11Ah
Weight 3.40kg
Dimensions L: 136mm W: 76mm H: 133mm
height with 1 spacer: 139mm height with 2 spacers: 154mm
Information
Features
QUADFLEX AGM BATTERY
The perfect battery for motorcycle, ATV's, Personal Watercraft and Snow Mobiles.
Used in Generators, Lawnmowers, Racing and other cycling/starting applications
Maintenance Free, AGM-DRY CELL technology.
More power and more Ah than nearly All other brands in this range.
CCA, CA, MCA, HCA + PHCA cranking ability.
Specifications
| Battery Type | MB9U | |
|---|---|---|
| Voltage | 12 | |
| CCA | 140 | |
| MCA | 201A | |
| PHCA | 385A | |
| Capacity (10HR) | 11Ah | |
| Weight | 3.40kg / 7.48Ibs | |
| Dimensions (in / mm) | L: 5.35(136) W: 2.99(76) H: 5.24(133) TH1: 5.48(139) TH2: 6.1(154) |
|
| Assembly Figure Terminal Locations | 4 |  |
| Terminals | 2, M6x2.5 | |
| Screws | 4, M6X7 | |
| Allen Wrench | 1, 4x4 | |
| Terminal Caps | 4, 12x5.5 | |
| Spacer | 2, Bottom Spacers. Spacer 1 = 6mm, Spacer 2 =15mm, Total = 21mm |
|
Applications
COMPATIBLE PART NUMBERS: MB9U, 12N73A, 12N73B, 12N7D3B, 12N74A, 12N74B, YB7A, YB7AA, YB7LA, YB7LB, YB9A,YB9AA, YB9A2, YB9LA2, YB9B, YB9LB, YB9B2, YB9LB2, 12N93A, 12N93A1, 12N93B, 12N94B1, YG7AA2YG7A, YG7LA, YG9LB, YG9B + OTHERS
