Battery Charger CTEK MXS 5.0 12 volt 5amp Charger

Battery Charger CTEK MXS 5.0 12 volt 5amp Charger
The MXS 5.0 is an advanced microprocessor controlled battery charger with automatic temperature compensation built in providing unrivalled performance on lead-acid batteries from 1.2Ah up to 110Ah. The MXS 5.0 solves a broad range of battery problems and is the ideal charger for the user with high demands.

Charger type 8 step, fully automatic charging cycle
Battery types All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity 1.2–110Ah up to 160Ah for maintenance

Click image for more information
Price:
NZ$ 245.70 including GST


or four payments of $61.43 with
Afterpay Payment Offer Learn More

each
MXS5.0
Out Of Stock
Out Of Stock

Features of the MXS 5.0 include diagnosis of battery condition to establish if it can receive and retain charge, patented automatic desulphation step and a special reconditioning step that will revive and restore deeply discharged and stratified batteries. AGM option is perfect for maximising performance and life of most Stop - Start batteries. The built in temperature compensation ensures ideal charging performance even in the most extreme conditions. Patented Float/Pulse maintenance makes the MXS 5.0 ideal for long - term maintenance. The entire process of battery testing, charging and maintenance is easily followed on the clear LED display.

The MXS 5.0 is a fully automatic "connect and forget" 12V charger with 8 charging steps and offers selectable SMALL BATTERY, and NORMAL BATTERY  programs. The RECOND and AGM options operate individually or together  in both SMALL BATTERY and NORMAL BATTERY programs providing great  flexibility for the user. Wide charging range on all lead-acid battery types  from 1.2Ah up to110Ah with additional maintenance capability to 160Ah.  Splash proof and dust proof (IP65).  The MXS 5.0 is easy and safe to use,  protects vehicle electronics, is spark-free, reverse polarity protected and short  circuit proof. The MXS 5.0 features a 5- year warranty.

DOWNLOAD BROCHURE HERE

DOWNLOAD MANUAL HERE

Step 4: Battery ready to use

Step 7: Fully charged battery

Step 8: Maintenance charging

COLD/AGM: Charging in cold conditions, AGM and Stop-Start batteries

RECOND: Recondition of deeply discharged batteries

SMALL: Program for charging small batteries

NORMAL: Program for charging normal batteries
Volt     12V
Rated Voltage AC     220–240VAC, 50–60Hz
Charging voltage     SMALL, NORMAL: 14.4V, COLD/AGM: 14.7V, RECOND: 15.8V
Min battery voltage     2.0V
Charging current     5A max
Current, mains     0.6A rms (at full charging current)
Back current drain     <1Ah/month
Ripple     <4%
Ambient temperature     -20°C to +50°C, output power is reduced automatically at high temperatures
Charger type     8 step, fully automatic charging cycle
Battery types     All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity     1.2–110Ah up to 160Ah for maintenance
Dimensions     168 x 65 x 38mm (L x W x H)
Insulation class     IP65
Weight     0.6kg
Temperaturkompensation     Built in charge voltage compensation according to ambient temperature
